Meridian M5Plus

Pocket-Sized IMU-RTK GNSS

M5Plus GNSS receiver is an extremely lightweight, full-featured, intelligent GNSS receiver system equipped with an integrated full-frequency antenna and advanced multi-channel RTK engine, built-in radio, and 8GB internal storage, allowing users to attain accurate, reliable solutions. Its powerful RTK algorithm makes M5Plus easy to get fixed solutions in the most demanding environments, brings you to focus on your surroundings and not the bubble to measure the points that previously could not be measured, making your stake out more efficiently and conveniently than ever before with increased speed, safety and comfort and greatly improving your working efficiency.

Multi Constellation

M5Plus provides an excellent onboard real-time navigation solution with high accuracy. Multi-satellite signals (GPS, GLONASS, BEIDOU, GALILEO, QZSS, IRNSS, L-Band) are included.

Powerful IMU Feature

Equipped with 120° calibration-free IMU technology in a small body, extending the M5Plus’s application range to locations that traditional RTK systems cannot reach, opening up new horizons for product applications.

Palm Size

The palm-sized RTK (Real-Time Kinematic) system combines elegance with precision, offering a compact solution for accurate positioning on the go.

Powerful Battery

With 7.2V 6600mah and quick-charge capability, it supports you in working more than 26 hours and greatly saves your time.

Rugged Housing

IP68 waterproof and dustproof design and magnesium-aluminum alloy housing.

Technical Specification

GNSS Signal②
Channel	1408
Beidou (BDS)	B1I，B2I，B3I，B1C，B2a，B2b*
GPS	L1 C/A，L1C*，L2P(Y)，L2C，L5
GLONASS	L1，L2，L3*
GALILEO	E1，E5a，E5b，E6*
QZSS	L1C/A，L1C， L2C，L5，L6*
SBAS	L1，L5*
NavIC(IRNSS)*	L5
L-band	B2b PPP (Only for the Asian-Pacific Region)&HAS*
Data Format
Format	CMR, CMR+, RTCM2.X, RTCM3.X
Data Output	NMEA-0183, RINEX, TXT
Data Updating Rate	Up to 20Hz
Time to Recapture	<1s
Cold Start	<40s
Positioning Performance
Single Point Positioning (RMS)	Horizontal: 1.5mm \| Vertical: 3.0mm
DGPS (RMS)	Horizontal: 0.4m \| Vertical: 0.8m
Real-Time Kinematic (RMS)	Horizontal: ±(8mm+1ppm) \| Vertical: ±(15mm+1ppm)
Speed Accuracy (RMS)	0.03m/s
Static Accuracy (RMS)	Horizontal: ±(2.5mm+0.5ppm) \| Vertical: ±(5mm+0.5ppm)
Time Accuracy (RMS)	20ns
Speed Accuracy	≥0.03m/s
Tilt Compensation Accuracy	≤2cm(Tilt Angle≤60°, Up to 120°)
IMU Update Frequency	200Hz
Communication
Bluetooth	V5.2 Dual Mode. 2.4GHz@+5dBm
Storage (USB Access Supported)	8GB
Internal Radio	Transmitting power: 1W (27 dBm +1.5 dB) or 2W (32 dBm +1.5 dB) Frequency: 410~470MHz. Channel Spacing: 25kHz Operation: Data Only, Antenna Impedance 50 Ohm Protocol: SOUTH, TRIMTALK 450S, TRIMMK III, TRANSEOT. SATEL. MERIDIANLINK Air Baud Rate: 9600,19200,11000
Battery
Specifications	7.2V 6600mAh lithium-ion Rechargeable Battery
Operating Time	RTK Rover: Up to 26 hours \| Static: Up to 30 hours
Charging	Support USB PD 15V/1.5A (Supports Quick Charging Adapter)
Environment
Operating Temperature	-40°C~+85°C
Storage Temperature	-55°C~+85°C
Anti-seismic	2m Pole Drop Onto Concrete
Dust & Waterproof	IP68
Physical
I/O Interface	1× USB type-C port; 1 × SMA antenna port; 1 × 5 pin LEMO port
Dimensions	119mm×119mm×76mm
Weight	599g
Material	Magnesium-alloy Casing + ABS/PC Plastic Top Cover
